Product Details:
|
| Warranty: | 3years | Type: | Synchronous Motor |
|---|---|---|---|
| Frequency: | 50/60Hz | Phase: | Three-phase |
| Protect Feature: | Waterproof | AC Voltage: | 208-230 / 240 V |
| Efficiency: | IE 2 | Design: | Permanent Magnet Synchronous |
| Rated Voltage: | 220V | Rated Power: | 750W |
| Rated Current: | 2.5A | Number Of Poles: | 32 |
| Rated Torque: | 80 N.M @80RPM | Speed Range: | 80-100 RPM |
| Applicative Blades Number: | 5 / 6 Blades | Motor Diameter: | 268mm |
| Applicative Diameter Of Fans: | 3.6m~ 4.8m | Port: | Shanghai |
Design | Permanent magnet synchronous |
Power | 500~1500W |
Fan length | 3-8M |
Air covered area | 280~1400㎡ |
Air volume | ≥203,800m³/h |
Noise level | 40dB |
Power supply | 220V/380V |
RPM range | 40-130RPM |
Blade material | aluminum |
Advantage | Maintenance free |
